Turbolader
4025225, 4025225NX, 4025225RX 4033210 4033210H 35964184 025225 | QSC4VKCEC | 4025225NX Holset Cummins
Geschikt voor:
Diverse voertuigen - zie onderdeelnummers voor compatibiliteit
Specificaties:
Motorcodes:
Zie productspecificaties
Onderdeelnummers:
3596418, 4025225, QSC4VKCEC, 4025225NX, 4025225RX,CUMMINS 4025225, 4033210, 3596418, 3596421, 3596431, 3596432, 3599602, 3596428, 3596420, 3596427, 3596424, 3596422, 4033210H, 4038651
2001- Cummins Truck Encore with 6C, 6CTAA, QSC4VKCEC Engine
2001- Cummins ENCORE Engine with 6C Engine
2001- Cummins ISC ENCORE Engine with 6C Engine
2001- Cummins LMRO with 6CTAA Engine
| Part Number |
3596418 |
| Previous Version |
3596420, 3596421, 3596422, 3596424, 3596427, 3596428, 3596431, 3596432, 3599602, 3538236, 3538237, 3538238, 4033654, 403365400, 403365400H, 4033654H, 4038651, 4033210H |
| OE number |
4025225, 4025225NX, 4025225RX |
| Description |
Truck, Industrial Encore Engine |
| CHRA |
3591196 (4027676, 3538379, 4027906)(1000020132) |
| Turbo Model |
HX40W-P8594L/H16UD8, HX40W |
| Engine |
6CTAA, 6C, QSC4VKCEC, 6CTAA-6C |
| Engine Manufacturer |
Cummins |
| Displacement |
8.3L, 8300 ccm |
| KW |
202/210/285 |
| Fuel |
Diesel |
| Bearing Housing |
3537112 (3593878, 4038197)(Oil Cooled)(1900011016A) |
| Turbine Wheel |
3522879 (3535359)(Ind. 64. mm, Exd. 76. mm, 12 Blades)(1100030008) |
| Comp. Wheel |
3599550 (Ind. 60. mm, Exd. 86. mm, Trm 49, 6+6 Blades, super back)(1200016210) |
| Back plate |
3530923 (1154351300, 1800016009) |
| Heat shield Number |
3519304 (3519302)(1152301340, 2030016031) |
| Repair Kit |
3575169 (1153035750, 5000020021) |
| Gasket (oil outlet) |
210060 (311585, 148062, 409267-0003, 409267-0002, 210060-0000, 51914)(Paper) |
| Gasket (oil inlet) |
409039-0000 (409039-0001, 210019, 312617, 2405022, 7C7431)(1900000006) (Inox Steel) |
| Gasket Kit |
3545575 |
| Replaces |
3596420,3596421, 3596422, 3596424, 3596427, 3596428, 3596431, 3596432 |
| Manufacturer |
HOLSET |
