Turbolader 3594085 3525505, 3525506, 3525507, 3592523, 3594086, 3594087, 3594088, 3594089 Cummins Holset
Geschikt voor:
Diverse voertuigen - zie onderdeelnummers voor compatibiliteit
Specificaties:
Motorcodes:
Zie productspecificaties
Onderdeelnummers:
CUMMINS 3594085
| Part Number |
3594085 |
| Previous versions |
3525504 |
| OE number |
503525504, 3803015 |
| Description |
Industrial Engine |
| Turbo Model |
HC5A, HC5A-2731U/B40D3 |
| CHRA |
3594216 $864.33 IN STOCK |
| Manufacturer number |
3525505, 3525506, 3525507, 3592523, 3594086, 3594087, 3594088, 3594089 |
| Engine Manufacturer |
Cummins |
| Engine Model |
KT-19, KT38, KTA19, KTA38, KT1150 |
|
| Source Reference |
3803103, 3803015 |
| KW |
450/525/925/1050 HP |
| Displacement |
19L, 1900 ccm |
| Fuel |
Diesel |
| Angle α (compressor housing) |
19/201/247/249.5° |
| Angle β (turbine housing) |
22.5/67.5/360° |
| Bearing Housing |
3595036 |
| Turbine Wheel |
3521033 (Ind. 129.0 mm, Exd. 95.4 mm, 11 Blades) (1152105435) |
| Comp. Wheel |
3523553 (352355300) |
| Back plate |
3524862 (352486200) |
| Heat shield Number |
3536588 (1153080340) |
| Repair Kit |
3545647 (3575236) (1152105750) |
| Turbine Housing |
3534201 |
| Compressor Cover |
3525546 |
| Gasket Kit |
4032509 |
| Gasket (turbine inlet) |
311698 (Inox Steel) |
| Replaces following turbo |
3525504, 3525505, 3525506, 3525507 |
|
| Manufacturer |
HOLSET |
Applications
2000- Cummins Industrial Engine with KT1150, KTA38 Engine
