Turbolader 471049-5004S | 471049-5004S RE508973 | 318614 S2A RE509817 Garrett Schwitzer John Deere
Geschikt voor:
Diverse voertuigen - zie onderdeelnummers voor compatibiliteit
Specificaties:
Motorcodes:
Zie productspecificaties
Onderdeelnummers:
471049-5004S, 471049-5004S, RE508973, RE509817, 5004SRE508973, RE528771, RE529468, RE530402, RE531054, RE534651, RE538363, RE548726, RE548728, RE548730, RE548732, RE548733, RE548735, RE60046, RE60076, RE67647, SE502162, SE502186, SE502378
| Part Number |
318615 |
| Previous Version |
318570, 174735 |
| Interchangeable |
RE503097, RE508876, RE508877, RE508971, RE509818, RE59379, RE59997, RE59999, RE60069, RE60076, RE67647, RE70995 |
| OE number |
RE508971, RE509818, RE523366, RE508973, 3990023112
|
| Interchangeable Turbo Part OE No |
471049-0001, 471049-0002, 471049-0003, 471049-0006, 471049-0008, 471049-9001, 471049-9004
|
| Year |
2000-12 |
| Description |
Gen Set |
| Manufacturer Part Number |
318570, 418570 |
| CHRA |
318613 (1000070100) |
| Interchangeable CHRA |
446311-0006 |
| Turbo Model |
S2A, S2A090, K27-112 |
| Engine Model |
4045 & 4045T |
| Displacement |
4.5L, 4500 ccm |
| KW |
102/137 |
| Fuel |
Diesel |
| Angle α (compressor housing |
24° |
| Angle β (turbine housing) |
0° |
| Bearing Housing |
318609 (Oil Cooled)(1900011197) |
| Turbine Wheel |
314653 (Ind. 52.8 mm, Exd. 61. mm, Trm 9.66, 10 Blades)(1100016532, 301030001, 1228000015) |
| Comp. Wheel |
197611 (409096-0008)(Ind. 38.1 mm, Exd. 60.95 mm, Trm 13.37, 6+6 Blades, Billet)(1200016743) |
| Back plate |
197340 (166537, 408045-0041)(1800016020) |
| Heat shield Number |
193975 (49168-18900)(1352346) |
| Repair Kit |
318477 (1252102750) |
| Turbine Housing |
318567 |
| Compressor Cover |
317367 |
| Gasket (turbine inlet) |
407294-0001 (310694, 312617)(303031063) |
| Gasket (oil outlet) |
210021 (148062, 210021-0000, , 311496, 3519807, 409037-0000, 413671-0000)(1900000027) |
| Gasket Kit |
318418 |
| Replaced By |
318614 |
| Manufacturer |
Borg Warner - 3K - Schwitzer, cz |
