Turbolader 465154-5026S | 465154-0003 | 465154-5026S2674352 Garrett
Geschikt voor:
Diverse voertuigen - zie onderdeelnummers voor compatibiliteit
Specificaties:
Motorcodes:
Zie productspecificaties
Onderdeelnummers:
465154-5026S, 465154-0003, 465154-5026S2674352, 5026S2674352, 2674A112
| Part Number |
310407 |
| Previous Part Number |
2674152, 2674356, 2674360, 2674388, 2674392, 2674393, 2674405, 310075, 310075R, 310407R, 317717, 317717R, 465154-0003 |
| OE number |
1447462M91, 2674405 |
| Year |
1984-01 |
| Description |
Tractor, Perkins Agricultural vehicle, Industrial Engine |
| Manufacturer Part Number |
465154-0001, 465154-0002, 465154-0003, 465154-0005, 465154-0019, 465154-0022, 465154-0023, 465154-0026 |
| CHRA |
310410 (310287) |
| Turbo Model |
S76 |
| Engine |
T6-354.4, T6-354.4 AG |
| Fuel |
Diesel |
| Angle α (compressor housing) |
290° |
| Angle β (turbine housing) |
255° |
| Bearing Housing |
310206 (Oil Cooled) |
| Turbine Wheel |
310207 |
| Comp. Wheel |
310205 (3763121) |
| Back plate |
197652 |
| Heat shield Number |
188276 (311599) |
| Repair Kit |
318385 (183223, 3545650, 188210-0000) |
| Turbine Housing |
310209 |
| Compressor Cover |
310204 |
| Gasket Kit |
468186-0000 (409036-0000, 407294-0001, 409037-0000)(FULK-2085)(2090505007) |
| NOTE |
Internal parts not interchangeable |
| Manufacturer |
Borg Warner - 3K - Schwitzer |
