Turbolader 3531032 3531032 3523245H 3802291 | 3802291RX | 3802588RX 3802291 H1C Holset CUMMINS H252670552 4BT 5.H1C
Geschikt voor:
Diverse voertuigen - zie onderdeelnummers voor compatibiliteit
Specificaties:
Motorcodes:
Zie productspecificaties
Onderdeelnummers:
3531032, 3802291, 3802291RX, 3802588RX,
3530734, 4027309, 3532205, 3531032, 3531032H
Weight 16.05 kg
| Part Number |
3531032 |
| Previous versions |
3523245, 3528745, 3528746, 3528748, 3530734, 3530740, 3531032, 3532205, 3533729, 3533730, 3533731 |
| OE number |
3802291, 3802291RX, 3802588, 3802588RX |
| Description |
Truck, Marine |
| Turbo Model |
H1C-8243AF/J13S5, H1C |
| CHRA |
3545699 (3545699H) |
| Manufacturer Part Number |
3534371, 3534372, 3802111, 3912972, 3919149, 3926199 |
| Displacement |
5.9L, 5900 ccm |
| Fuel |
Diesel |
| Engine |
4BT, 6BT |
| Engine Manufacturer |
Cummins |
| Angle α (compressor housing) |
241° |
| Angle β (turbine housing) |
301° |
| Bearing Housing |
3530591 (3500591, 3500592, 3530592)(Oil Cooled)(1152301450, 1900011017) |
| Turbine Wheel |
3503798 (Ind. 70. mm, Exd. 57. mm, Trm 10.69, 12 Blades) |
| Rotor Assembly |
3545526 |
| Comp. Wheel |
3503798 (3521711, 3599639)(Ind. 49.98 mm, Exd. 82.04 mm, Trm 9.95, 8+8 Blades, Superback)(1152301400, 1200016055) |
| Back plate |
3522801 (3534947, 167543)(1300016005) |
| Heat shield Number |
3519302 (3519304, 167550)(1152301340, 2030016031) |
| Repair Kit |
3545652 (3802148, 4027309)(1152301750, 5000020014) |
| Turbine Housing |
Water Cooled |
| Gasket Kit |
3545769 |
| Manufacturer |
HOLSET |
| |
Orderable Part# |
Service Name |
|
3545699H |
CHRA,(CORE ASSEMBLY) |
|
3545769H |
GASKET KIT |
|
4027309H |
REPAIR KIT,(MAJOR) |
|
3519805H |
GASKET,(OIL DRAIN) |
| Engine Manufacturer |
Engine Model |
Engine Capacity |
Power Rating (HP) |
Engine Speed (RPM) |
Emissions |
Vehicle Manufacturer |
Vehicle Type |
| CUMMINS |
4BT |
3.9 |
- |
