Turbolader IVECO 4046551 D0904271539 4033378 NEF 6CYL 4V TAA FIAT AGRI 243 HP TIER 3 504229708 HX35W HOLSET CUMMINS NEW HOLLAND
Geschikt voor:
Diverse voertuigen - zie onderdeelnummers voor compatibiliteit
Specificaties:
Motorcodes:
Zie productspecificaties
Onderdeelnummers:
IVECO 4033378, 4046551, 4033378H, 5353736, 504229708, 1856676, 2856676, 4046552, 4033378, 504229708, 1856676, 4033378, 4033378H, 4046551, 4046552, 5353736
| Engine Manufacturer |
Engine Model |
Engine Capacity |
Power Rating (HP) |
Engine Speed (RPM) |
Emissions |
Vehicle Manufacturer |
Vehicle Type |
| FIAT |
NEF 6CYL 4V TAA |
- |
243 HP |
- |
TIER 3 |
IVECO |
TRACTOR |
| Assembly |
4046551 |
| Kits Available |
Not Available |
| Latest Supersession |
5353736 |
| Model |
HX35W |
| OEM Customer# |
504229708 |
| OEM Supplied# |
4046552 |
| Status |
Superseded |
| Turbocharger Make |
HOLSET |
| Orderable Part# |
Service Name |
|
3545575H |
GASKET KIT |
|
4027339H |
BRACKET KIT |
|
4027448H |
REPAIR KIT,(MAJOR) |
|
3599650H |
COMPRESSOR WHEEL |
|
2839879H |
CLAMP PLATE,(TURBINE) |
| Part Number |
5353736 |
| Previous Version |
4033378, 403337800, 4033378H, 4046551, 4046552 |
| OE number |
504229708 |
| Description |
Iveco Tractor |
| CHRA |
4032389 (403238900, 4032389H) |
| Turbo Model |
HE300FG |
| Engine |
NEF 6 Cylinders 4V TAA |
| Engine Manufacturer |
Iveco |
| Displacement |
6 Cylinders |
| KW |
243 HP |
| Fuel |
Diesel |
| Angle α (compressor housing) |
251º |
| Angle β (turbine housing) |
15º |
| Bearing Housing |
4032032 (Oil Cooled)(1900011016F) |
| Turbine Wheel |
3595832 (3519336) (Ind. 69.97 mm, Exd. 60. mm, Trm 10.82, 12 Blades)(1152301435, 1100016442) |
| Comp. Wheel |
3599650 (3599594)(Ind. 51.76 mm, Exd. 76.2 mm, Trm 10.1, 7+7 Blades, Superback)(1200016437) |
| Back plate |
3596448 (359644800)(1800016009) |
| Heat shield Number |
3519302 (3519304)(1152301340, 2030016031) |
| Repair Kit |
4027448 (Minor)(1153035751, 5000020021) |
| Gasket Kit |
3545575 (1900100057) |
| Manufacturer |
HOLSET |
